Underwater NaI(Tl) Detector
Description: 2 inch x 2 inch NaI(Tl) scintillation detector
Features:
◼ Scintillation crystal：NaI(Tl) 2 inch x 2 inch
◼ Photomultiplier tube: 2 inch PMT CR105-5
◼ Built-in ultra stable High Voltage
◼ Built-in preamplifier and spectroscopic amplifier
◼ Ruggedised assembly
◼ The whole detector body is made of SS and also leak and water proof
Specifications：
⚫ High voltage regulation: 300 - 1500 V
⚫ Power supply : + 5V
⚫ Pulse shape: 2us
⚫ Energy range: 50KeV to 3MeV
⚫ Connectors: 5-core shielded cable for signal output and powder supply
⚫ HV test Point: No
⚫ HV adjust Point: No
Sizes and Material：
◆ Probe length (Detector + PMT + Electronic): 310mm
◆ Probe casing and support material: Stainless Steal
◆ Diameter of probe: 65 mm
◆ Diameter of support to fix the probe in pot: 86 mm
◆ Thickness of support: 10 mm
◆ Six holes of dia.5mm to 60 degree at PCD 78 mm of support to fix the
probe in pot
